Skydroid H16 All-in-one Portable Ground Control Station

Available: In Stock
$299.00
  • Order within

H16 is a portable and cost-effective ground control station with video link, data link, rc and android system all in one, featuring low latency, good anti-interference performance and long transmission range.

H16 series includes two versions: H16 and H16 Pro. The max transmission range of H16 is 10km, H16 Pro-30km.


-H16 series GCS is equipped with a 7'' FHD high-brightness screen with a resolution of 1920*1200, Max. brightness can reach 2000nit,operators can use it in full sunlight.


-Equipped with an android system, H16 series supports mainstream ground station software like QGC. So it can achieve functions like route planning, real-time flight status feedback etc. It also supports video suspension and wireless RTSP video streaming sharing.


-H16 series features high expansibility, supports multiple interface like HDMI, RJ45, SBUS, PPM,sensor interface, UART, USB etc.


-H16 includes a MIPI camera, the resolution of which is 1080P.


-The GCS body, control switches and all peripheral interfaces adopt dust-proof and water-proof design, which can ensure stable and smooth operation in harsh environments.


-With an built-in 20000mAh li-ion battery, the operation time is up to 8hours with full capacity, MX16 supports 18w fast charge.


-The H16 series GCS is compatible with most of drones,  which can be used for powerline inspection, police patrol, search and rescue etc.


Specification:
Weight: 1034g(controller)
Channel: 16
Working voltage: 4.2V
Frequency: 2.400GHz-2.483GHz
Battery Capacity: 20000mAh
Endurance: 8hours
Communication technology: FHSS
Transmission Distance: 10km; 30km (Video/data)
Receiver:
Working Voltage:7.2-72V
Size:76*59*11mm
Weight:90g
MIPI Camera:
Working Current: 14mA;140mA(with the light on)
Working Voltage:14-72V
Size:102.1*42.6*36.5mm
Weight:55g

Your Purchase Includes:
1x H16/H16 Pro Ground Control Station
1x H16/H16 Pro Air Unit
1x MIPI Camera
2x Antenna for Ground Control Station
1x Charger for Ground Control Station
1x Type-C to HDMI Conversion  Module
1x Neck Strap
1x Cable Package

H16 is a portable and cost-effective ground control station with video link, data link, rc and android system all in one, featuring low latency, good anti-interference performance and long transmission range.

H16 series includes two versions: H16 and H16 Pro. The max transmission range of H16 is 10km, H16 Pro-30km.


-H16 series GCS is equipped with a 7'' FHD high-brightness screen with a resolution of 1920*1200, Max. brightness can reach 2000nit,operators can use it in full sunlight.


-Equipped with an android system, H16 series supports mainstream ground station software like QGC. So it can achieve functions like route planning, real-time flight status feedback etc. It also supports video suspension and wireless RTSP video streaming sharing.


-H16 series features high expansibility, supports multiple interface like HDMI, RJ45, SBUS, PPM,sensor interface, UART, USB etc.


-H16 includes a MIPI camera, the resolution of which is 1080P.


-The GCS body, control switches and all peripheral interfaces adopt dust-proof and water-proof design, which can ensure stable and smooth operation in harsh environments.


-With an built-in 20000mAh li-ion battery, the operation time is up to 8hours with full capacity, MX16 supports 18w fast charge.


-The H16 series GCS is compatible with most of drones,  which can be used for powerline inspection, police patrol, search and rescue etc.


Specification:
Weight: 1034g(controller)
Channel: 16
Working voltage: 4.2V
Frequency: 2.400GHz-2.483GHz
Battery Capacity: 20000mAh
Endurance: 8hours
Communication technology: FHSS
Transmission Distance: 10km; 30km (Video/data)
Receiver:
Working Voltage:7.2-72V
Size:76*59*11mm
Weight:90g
MIPI Camera:
Working Current: 14mA;140mA(with the light on)
Working Voltage:14-72V
Size:102.1*42.6*36.5mm
Weight:55g

Your Purchase Includes:
1x H16/H16 Pro Ground Control Station
1x H16/H16 Pro Air Unit
1x MIPI Camera
2x Antenna for Ground Control Station
1x Charger for Ground Control Station
1x Type-C to HDMI Conversion  Module
1x Neck Strap
1x Cable Package
